This combined text and lab manual which covers the basics of electricity and electronics theory. Thoroughly revised, it is designed as an introductory course for electronic service technicians. It is also well suited for use in technical schools as a principle lab manual in typical one-year courses. Emphasis is placed on the commonsense manner of understanding or trouble-shooting circuitry. Experiments, which use commonly available components, are written in a down-to-earth style, so that the student can grasp the most fundamental concepts. Experimental procedures require the student to think and make decisions. Summaries, self-tests and questions are included throughout the text.

Chapter 1 Using the Multimeter Chapter 2 Series and Parallel Resistance Circuits Chapter 3 Voltage and Voltage Measurement Chapter 4 Measurement and Control of Direct Current Chapter 5 Ohm's Law and the Series Circuit Chapter 6 The Parallel Circuit Chapter 7 Series-Parallel Circuits Chapter 8 Kirchhoff's Laws Chapter 9 Thevenin's Theorem Chapter 10 Power Chapter 11 Electricity and Magnetism Chapter 12 Alternating-Current Measurement Chapter 13 Capacitors Chapter 14 Capacitive Reactance and Phase Measurement Chapter 15 Inductance Chapter 16 Series RC and RL Circuit Characteristics Chapter 17 The Series-Resonant Circuit Chapter 18 Rarallel Reonance Chapter 19 Power in AC Circuits Chapter 20 Filter Circuits Chapter 21 Nonlinear Devices Chapter 22 Semiconductor Diodes Chapter 23 Diode Dircuits Chapter 24 Power Supply Circuits Chapter 25 Junction Transistors Chapter 26 Common-Emitter Amplifier Characteristics Chapter 27 The Emitter-Follower Amplifier Chapter 28 Advanced Transistor Amplifier Circuits Chapter 29 Audio Amplifier Characteristics Chapter 30 Differential AMplifier Chapter 31 Field-Effect Transistors and Amplifiers Chapter 32 Linear Integrated Circuits Chapter 33 Op Amp Circuits Chapter 34 Advanced Power Supply circuits Chapter 35 Oscillators Chapter 36 Multivibrators Chapter 37 555 Timer Chapter 38 Large-Scale IC Signal Generation Chapter 39 Signal Control Circuits Chapter 40 Solid-State Switches Chapter 41 Digital IC Gate Circuits Chapter 42 Analog-to-Digital Conversion Chapter 43 Digital-to-Analog Conversion Chapter 44 Digital IC Counters Chapter 45 Digital IC Decoders Appendix A Appendix B Appendix C
